Fiberglass consumer units FHS
.jpg)
Fiberglass (thermosetting GRP) distribution boards FHS are a range of products for heavy duty uses with IP66 protection class and resistant to UV rays. They are suitable for example for PV plants, cement plants, mineral oil extraction plants, nuclear plants and laboratories, commercial and exhibition activities, airports, railway and underground facilities.
The system is composed of 7 sizes in the versions with blind door which allows an opening wider than 180°. Thanks to the clipping system of internal mounting frame for modular devices wiring can be done on the bench, out of the board or directly inside the board.
The accessories to use the board in typical configurations of automation are the backplates, inner door, functional frame, front panels with DIN rails and others.
- Fiberglass (thermosetting GRP) distribution boards FHS
- In conformity to EN 62208 standard
- Variants for surface mounting
- Degree of protection IP66
- Resistance to impacts IK10
- Light grey RAL 7035 colour
- Design offerings extra space inside
- Robust steel internal mounting frame for modular devices with clipping system for easy mounting and setting to the board
